Directives
The directives this theme adds to what an author can write, and the document
field. They are registered by the extension, so a project that selected the
theme can use them immediately — there is nothing to add to guides.xml and
no template to copy.
:layout:hero.sds-split and sds-figureband.sds-bandgridsds-gridsplit.sds-splithalf.sds-stackcardsds-cardstatsds-statsurfacesds-surfacequotesds-quotebuttonsds-buttonbutton-bar.sds-actionsaccordion, accordion-itemsds-accordionexamplesds-code in .sds-examplespecimensds-embed| Written | What it is for | Draws |
|---|---|---|
:layout: |
a field, not a directive: which of the two shapes the page is built in | — |
hero |
the opening claim of a landing page, beside one image | .sds-split and sds-figure |
band |
a full-bleed section of a landing page, and everything after it | .sds-band |
grid |
a set read side by side, reflowing by its own minimum width | sds-grid |
split |
two of anything, side by side until there is no room for two | .sds-split |
half |
one side of a split, where that side is several blocks | .sds-stack |
card |
a way into something: a title that goes somewhere, and what is behind it | sds-card |
stat |
one number stated as a fact | sds-stat |
surface |
one filled plane, stating something in place | sds-surface |
quote |
a sentence borrowed from somewhere, with where it came from | sds-quote |
button |
one press, and where it goes | sds-button |
button-bar |
the presses of a page, standing in one row | .sds-actions |
accordion, accordion-item |
questions with their answers folded behind them | sds-accordion |
example |
a piece of markup and, under it, what it renders as | sds-code in .sds-example |
specimen |
a rendered card, embedded at the size it was measured at | sds-embed |
Each of them draws an element of this system and takes that element's own
options, spelt the way the element spells them — so href links and src
takes a file here as everywhere else, and what a component gains the directive
gains with it. Every section below names the element it draws, and
Components is where that element's own reference is.
Every example on this page is written once: the block is the body that drew
the thing under it, which is what example is for.
layout#
Not a directive — a field at the top of a document, beside the navigation title, and it decides which shape the page is built in.
:navigation-title: Overview
:layout: marketing
================
What this is for
================:navigation-title: Overview
:layout: marketing
================
What this is for
================
marketing renders the page as a run of full-bleed bands with no rail.
Anything else — and any page that writes no such field — is the manual
shape: the toctree in a rail on the left, the trail above the title, the
text held to sixty-six characters.
-
layout# -
- type
- string
- default
- "default"
marketingrenders the page as a run of full-bleed bands with no rail. Anything else — and any page that writes no such field — is the manual shape: the toctree in a rail on the left, the trail above the title, the text held to sixty-six characters.
Both shapes carry the same bar and the same footer, because a reader must never have to work out which site they are on. What changes is the body.
A field is only invisible because something claimed it. One nobody claims
renders as a definition list in the body, which is what a misspelling looks
like: :laoyut: marketing prints the word and the value above the title
of a page that is still a manual.
A field is only invisible because something claimed it. One nobody claims
renders as a definition list in the body, which is what a misspelling looks
like: :laoyut: marketing prints the word and the value above the title
of a page that is still a manual.
hero#
The opening claim of a marketing page, set beside one decorative image. It goes immediately after the document title so that the title remains the page's real heading, browser title and source for navigation.
.. hero:: /_images/design-system-workbench.png
The opening summary belongs inside the directive.
A second paragraph can make the promise concrete... hero:: /_images/design-system-workbench.png
The opening summary belongs inside the directive.
A second paragraph can make the promise concrete.
The opening summary belongs inside the directive.
A second paragraph can make the promise concrete.
The document title stands above it in the source and is not part of it. The argument is the image source. The theme composes the existing split, stack and figure vocabulary; at a narrow viewport that split becomes a column by the same rule as every other split in the system. Content that follows the hero before the next band remains part of the opening section.
What the image shows when it contributes meaning not carried by the copy. Leave it out for a decorative illustration whose subject is already named beside it.
-
alt# -
- type
- string
- default
- ""
What the image shows when it contributes meaning not carried by the copy. Leave it out for a decorative illustration whose subject is already named beside it.
band#
A full-bleed section of a landing page: the ground runs edge to edge and the content inside is held to the page measure.
.. band:: This heading is a band, on a manual page
:quiet:
:id: a-band
And the paragraph after it, beside the section
rather than inside it: what follows a band
belongs to it on a page built out of bands,
and this page is not one... band:: This heading is a band, on a manual page
:quiet:
:id: a-band
And the paragraph after it, beside the section
rather than inside it: what follows a band
belongs to it on a page built out of bands,
and this page is not one.
This heading is a band, on a manual page
And the paragraph after it, beside the section rather than inside it: what follows a band belongs to it on a page built out of bands, and this page is not one.
On a page whose layout is not marketing, that is the whole of it — a
section inside the column rather than a ground running edge to edge, because
the shape a band takes is the page's to decide and not the band's.
A band does not wrap a page in itself, it opens one. What follows belongs to it until the next band starts, and what stands before the first one is a band as well — a page opens on the canvas. That is the whole of the syntax, and it has a reason beyond looking tidy in the source: a band is full-bleed and takes the page inset itself, so a band nested in another indents its text by a gutter nobody asked for and stops at the width of its parent.
.. band:: What it costs
:quiet:
:id: pricing
Everything from here, up to the next band.
.. band::
And this is back on the canvas... band:: What it costs
:quiet:
:id: pricing
Everything from here, up to the next band.
.. band::
And this is back on the canvas.
That one is printed rather than shown, and it is the only source on this page that is: what a band does with the content after it happens where the page is built out of bands, so rendered here it would be two sections with the text loose between them — which is what the example above is showing.
A page that writes no band at all is the single band it looks like.
The second ground. Alternating quiet and plain is what makes a run of bands read as a sequence rather than as a wall; two consecutive bands share one hairline rather than drawing two.
-
quiet# -
- type
- flag
The second ground. Alternating quiet and plain is what makes a run of bands read as a sequence rather than as a wall; two consecutive bands share one hairline rather than drawing two.
An anchor, so a link elsewhere on the site can land on this section.
-
id# -
- type
- string
An anchor, so a link elsewhere on the site can land on this section.
The band's argument. It is an option rather than a section heading because a
section heading inside a directive is not one: reStructuredText parses
sections at document level, so a line with ==== under it written in here
ships both the line and the equals signs as text.
-
the heading# -
- type
- string
The band's argument. It is an option rather than a section heading because a section heading inside a directive is not one: reStructuredText parses sections at document level, so a line with
====under it written in here ships both the line and the equals signs as text.
The landing page of the example project is the same directive where it is at home, with the run of them doing what the source says.
grid#
A set read side by side, reflowing by its own minimum width.
.. grid::
.. card:: What it is
:href: /guides-theme/index
:tag: Overview
Two sentences, a badge above the title,
and the whole card lit at the top of its
frame under the pointer.
.. card:: What it costs
:href: /guides-theme/installation
:tag: Installation
One Composer package, one copy step, and
a document called ``index`` at the root... grid::
.. card:: What it is
:href: /guides-theme/index
:tag: Overview
Two sentences, a badge above the title,
and the whole card lit at the top of its
frame under the pointer.
.. card:: What it costs
:href: /guides-theme/installation
:tag: Installation
One Composer package, one copy step, and
a document called ``index`` at the root.
Two sentences, a badge above the title, and the whole card lit at the top of its frame under the pointer.
What it is
Two sentences, a badge above the title, and the whole card lit at the top of its frame under the pointer.
One Composer package, one copy step, and
a document called index at the root.
What it costs
One Composer package, one copy step, and
a document called index at the root.
Two sentences, a badge above the title, and the whole card lit at the top of its frame under the pointer.
What it is
Two sentences, a badge above the title, and the whole card lit at the top of its frame under the pointer.
One Composer package, one copy step, and
a document called index at the root.
What it costs
One Composer package, one copy step, and
a document called index at the root.
No column count, and that is the design: three across on a desk, two on a
tablet, one on a phone, decided by how narrow an item may get rather than by a
breakpoint somebody picked. It holds cards, figures, or anything else read as
a set — each item draws itself and the grid only decides how many stand in a
row. The element is sds-grid in Content.
How much room one item needs, said as what the items hold rather than as a
number: wide for a card carrying a picture and a paragraph, dense
for a figure or a name and a glyph, flush for the gutter taken out so
the set shares a hairline and reads as one wall. Left off, the set gets the
width every set gets. A name the element does not define is not an
invitation to invent one — it falls back rather than passing through.
:variant: says the same thing as an option.
-
the argument# -
- type
- default | wide | dense | flush
How much room one item needs, said as what the items hold rather than as a number:
widefor a card carrying a picture and a paragraph,densefor a figure or a name and a glyph,flushfor the gutter taken out so the set shares a hairline and reads as one wall. Left off, the set gets the width every set gets. A name the element does not define is not an invitation to invent one — it falls back rather than passing through.:variant:says the same thing as an option.
Carried onto the element, because an author who wrote it meant it for their own stylesheet, and dropping what a theme does not understand is the one thing it must not do.
-
class# -
- type
- string
Carried onto the element, because an author who wrote it meant it for their own stylesheet, and dropping what a theme does not understand is the one thing it must not do.
split#
Two of anything, side by side until there is no room for two.
.. split::
:align: center
A paragraph and a picture are two blocks,
so they stand as two columns and nothing
here says which is which.
.. figure:: /_images/design-system-workbench.png
:alt: The workbench, beside the paragraph.. split::
:align: center
A paragraph and a picture are two blocks,
so they stand as two columns and nothing
here says which is which.
.. figure:: /_images/design-system-workbench.png
:alt: The workbench, beside the paragraph
A paragraph and a picture are two blocks, so they stand as two columns and nothing here says which is which.
Every block in it is a column. That is the whole rule, and it is why the
example above needs nothing to mark its halves — a paragraph is one block and
a figure is another. The moment a side is a heading, its paragraph and a press,
those are three columns unless something says where the side ends, and
half is that something. No width and no count anywhere: the halves fold
under each other by their own minimum, the way every set in this system
reflows. The class is .sds-split in Page layout.
Where the shorter half stands against the taller one — at the top, level
with it, or at the foot. start is what a split gets unless it says
otherwise, and center is what a line beside a picture usually wants.
-
align# -
- type
- start | center | end
Where the shorter half stands against the taller one — at the top, level with it, or at the foot.
startis what a split gets unless it says otherwise, andcenteris what a line beside a picture usually wants.
Which half is read first once the two have stacked. start is the order
they are written in; end puts the second half above the first, which is
a picture standing to the end of the line on a page and above the sentence
it illustrates on a phone. It changes nothing while the two fit side by
side — reading order is not source order at every width, and this is the
one thing about that which the layout cannot work out for itself.
-
leads# -
- type
- start | end
Which half is read first once the two have stacked.
startis the order they are written in;endputs the second half above the first, which is a picture standing to the end of the line on a page and above the sentence it illustrates on a phone. It changes nothing while the two fit side by side — reading order is not source order at every width, and this is the one thing about that which the layout cannot work out for itself.
Carried onto the split, because an author who wrote it meant it for their own stylesheet, and dropping what a theme does not understand is the one thing it must not do.
-
class# -
- type
- string
Carried onto the split, because an author who wrote it meant it for their own stylesheet, and dropping what a theme does not understand is the one thing it must not do.
half#
One side of a split: the blocks that stand together as a single column.
.. split::
:leads: end
.. half:: Two paragraphs, one side
This is the first of them, and it is not a
column.
This is the second, and without the
``half`` around both it would be one.
.. half::
.. figure:: /_images/design-system-workbench.png
:alt: The workbench, read before the text on a phone.. split::
:leads: end
.. half:: Two paragraphs, one side
This is the first of them, and it is not a
column.
This is the second, and without the
``half`` around both it would be one.
.. half::
.. figure:: /_images/design-system-workbench.png
:alt: The workbench, read before the text on a phone
Two paragraphs, one side
This is the first of them, and it is not a column.
This is the second, and without the
half around both it would be one.
It takes no position of its own: where a half stands is the split's decision,
because the other half is what it is standing against. Written anywhere else
it is simply the blocks it holds, in the rhythm a page keeps between them.
Its optional argument becomes an h2 inside the column. Use it when the
heading names that side rather than both sides of the split; a reStructuredText
section heading cannot be nested inside a directive.
Carried onto the column, for the reason split carries it.
-
class# -
- type
- string
Carried onto the column, for the reason
splitcarries it.
card#
One card: a title that goes somewhere, and what is behind it.
.. card:: :doc:`installation`
:label: Chapter
:icon: actions-book
:footer: For a desk
:action: Read it
What the package needs, and the commands that
render a project with it... card:: :doc:`installation`
:label: Chapter
:icon: actions-book
:footer: For a desk
:action: Read it
What the package needs, and the commands that
render a project with it.
What the package needs, and the commands that render a project with it.
A document, written the way a :doc: reference is, and resolved per
page. It is the same thing the title's own reference says, for a card whose
title is plain text — and where both are written, this one wins.
-
href# -
- type
- string
A document, written the way a
:doc:reference is, and resolved per page. It is the same thing the title's own reference says, for a card whose title is plain text — and where both are written, this one wins.
The tracked-out line over the title: what a set of cards is named or
numbered as — CHAPTER 02, FOR EDITORS — or when an entry is from.
The same register and the same line.
-
label# -
- type
- string
The tracked-out line over the title: what a set of cards is named or numbered as —
CHAPTER 02,FOR EDITORS— or when an entry is from. The same register and the same line.
What kind of thing the card is, in the badge beside the label. A fact about the card rather than a result, so it carries no tone and no glyph. The row is dropped where neither this nor the label is written.
-
tag# -
- type
- string
What kind of thing the card is, in the badge beside the label. A fact about the card rather than a result, so it carries no tone and no glyph. The row is dropped where neither this nor the label is written.
A glyph above the label, for a set told apart before it is read. The name is an icon of this system — see Icons.
The picture, flush at the top of the card. A path in the documentation
source is copied into the output and resolved per page; a URL somewhere else
is linked as it stands. Either way it is one <img>, so a drawing arrives
in the colours its file declares — Artwork says why,
and what the file is written to be ready for.
The name is src here and on the element, because that is what everything
in this system that takes a file is called.
-
src# -
- type
- string
The picture, flush at the top of the card. A path in the documentation source is copied into the output and resolved per page; a URL somewhere else is linked as it stands. Either way it is one
<img>, so a drawing arrives in the colours its file declares — Artwork says why, and what the file is written to be ready for.The name is
srchere and on the element, because that is what everything in this system that takes a file is called.
What the picture shows, for a reader who cannot see it. Written and empty says decorative — a card whose art only repeats the title beside it — and left out entirely says nothing was decided, which reads very differently.
-
alt# -
- type
- string
What the picture shows, for a reader who cannot see it. Written and empty says decorative — a card whose art only repeats the title beside it — and left out entirely says nothing was decided, which reads very differently.
One line under a hairline at the foot of the card: what the reader gets there, who it is for, what state it is in.
-
- type
- string
One line under a hairline at the foot of the card: what the reader gets there, who it is for, what state it is in.
The call to action, in words — Read it. It is not a button and not a
second link: the whole card already goes there, so this is the line that
says so, and the arrow after it leans out when the card is under the
pointer. Drawn only where the card has somewhere to go.
-
action# -
- type
- string
The call to action, in words —
Read it. It is not a button and not a second link: the whole card already goes there, so this is the line that says so, and the arrow after it leans out when the card is under the pointer. Drawn only where the card has somewhere to go.
Carried onto the element, for the reason the grid's is.
-
class# -
- type
- string
Carried onto the element, for the reason the grid's is.
The title carries the target. `.. card:: :ref:Introduction
<introduction>``` is how a TYPO3 manual writes a card, so the words of the
reference become the heading and the reference itself becomes where the card
goes. A plain title with :href: says the same thing the other way round.
The whole card is the link, and there is exactly one. The title's anchor is stretched over the frame, so what a screen reader announces is the title while what a pointer can hit is the card — and a second anchor inside it would be a second destination under one frame, which is why there is no option for a button. A link written into the prose of a card still works, and is a card asking to be two cards.
The options are ``sds-card``'s properties, all of them, spelt the way the
element spells them. A directive that draws one of this system's components
and answers for half of it sends the author who wanted the other half to their
own stylesheet, which is the one thing this system exists to prevent — and one
that renames what it does carry makes them translate a card they have already
read. href links and src takes a file here for the same reason they do
everywhere else. What the element gains, this gains — its reference is
sds-card in Content.
The node is sds-card itself and not a div wearing its classes — the
element is the front door here as everywhere else, so the card is drawn in one
file and a rendered page cannot drift from one a product wrote. The template
writes none of the card: it sets the options above and lets the element draw
its own markup, which is what makes the card the component's to change.
A reader with no JavaScript gets the whole of it anyway. Every element in the site is rendered before the page is published, so the picture, the row, the title and the summary are in the document with no script involved; in a browser the element upgrades over that rendering. This is the theme-wide arrangement, not the card's own — see Core markup, and what it becomes.
stat#
One number stated as a fact: the figure, what was counted, and the line that bounds it.
.. grid:: dense
.. stat:: 240
:unit: ms
:label: median answer
:icon: actions-clock
Measured over the last release, on a warm index.
.. stat:: 2
:of: 3
:label: sources answering
One is slow and one is unreachable from the checker... grid:: dense
.. stat:: 240
:unit: ms
:label: median answer
:icon: actions-clock
Measured over the last release, on a warm index.
.. stat:: 2
:of: 3
:label: sources answering
One is slow and one is unreachable from the checker.
Measured over the last release, on a warm index.
Measured over the last release, on a warm index.
One is slow and one is unreachable from the checker.
One is slow and one is unreachable from the checker.
Measured over the last release, on a warm index.
Measured over the last release, on a warm index.
One is slow and one is unreachable from the checker.
One is slow and one is unreachable from the checker.
The figure — 5, 240, 12.4+ — never "many". It is the argument
rather than an option because it is what the line is about.
-
the argumentrequired # -
- type
- string
The figure —
5,240,12.4+— never "many". It is the argument rather than an option because it is what the line is about.
What the figure is in — ms, %, kB. The element sets it a step
down and joins it to the number with the narrow no-break space a figure may
not be split from, so no page has to know that character.
-
unit# -
- type
- string
What the figure is in —
ms,%,kB. The element sets it a step down and joins it to the number with the narrow no-break space a figure may not be split from, so no page has to know that character.
What was counted, under the figure and in the label register.
-
label# -
- type
- string
What was counted, under the figure and in the label register.
The whole the figure is a part of, said after it — 2 of 3. Only where
the figure really is a part: a measurement is out of nothing. It is words
and not a bar, so every figure in a set keeps the same shape and their notes
start on one line.
-
of# -
- type
- string
The whole the figure is a part of, said after it —
2 of 3. Only where the figure really is a part: a measurement is out of nothing. It is words and not a bar, so every figure in a set keeps the same shape and their notes start on one line.
A glyph on the figure's line, before the number. Muted and never in a status colour, for the reason a card's is: a figure is a subject, not a result.
-
icon# -
- type
- string
A glyph on the figure's line, before the number. Muted and never in a status colour, for the reason a card's is: a figure is a subject, not a result.
Carried onto the element, for the reason the grid's is.
-
class# -
- type
- string
Carried onto the element, for the reason the grid's is.
The body is the bound, and it is not optional in practice. "5 sources"
says nothing until it says which five, and a figure with no bound is a claim
rather than a fact — which is the whole reason sds-stat is a component and
not two divs. It is written between the tags rather than as an option because
out of a document that line carries links.
A set of figures is a set, so it goes in grid like any other, at
dense — the width a number and the line under it holds. flush works
too: there the figures share a hairline and the wall gives each its ground.
The frame in a wall is the wall's, so a figure anywhere else stays bare and a
row of numbers on a page is not a row of boxes. The element is sds-stat
in Content, beside the grid it stands in.
surface#
One filled plane, stating something in place.
.. grid::
.. surface:: Read, never write
:icon: actions-file-shield
Every source is read. Nothing is written back.
.. surface:: One answer, one origin
:label: Rule 02
Two answers that disagree are told apart by
where they came from... grid::
.. surface:: Read, never write
:icon: actions-file-shield
Every source is read. Nothing is written back.
.. surface:: One answer, one origin
:label: Rule 02
Two answers that disagree are told apart by
where they came from.
Every source is read. Nothing is written back.
Every source is read. Nothing is written back.
Two answers that disagree are told apart by
Two answers that disagree are told apart by
where they came from.
Every source is read. Nothing is written back.
Every source is read. Nothing is written back.
Two answers that disagree are told apart by
Two answers that disagree are told apart by
where they came from.
The title of the plane, in the quieter register — this is not a destination, and a title that looks like one is a promise the box does not keep.
-
the argumentrequired # -
- type
- string
The title of the plane, in the quieter register — this is not a destination, and a title that looks like one is a promise the box does not keep.
The fill: raised, which sits on the canvas and reads as a plane, or
sunken, which is machine output — code, logs, structured content. Named
for the fill because in a system with no shadows that is what tells two
planes apart. raised is what a plane writing nothing is.
-
plane# -
- type
- string
The fill:
raised, which sits on the canvas and reads as a plane, orsunken, which is machine output — code, logs, structured content. Named for the fill because in a system with no shadows that is what tells two planes apart.raisedis what a plane writing nothing is.
The tracked-out line over the title, where a set is numbered or sourced —
AUDIENCE 01, SOURCE, STEP 02. Over the title rather than in it:
a title carrying its own number reads as part of the sentence.
-
label# -
- type
- string
The tracked-out line over the title, where a set is numbered or sourced —
AUDIENCE 01,SOURCE,STEP 02. Over the title rather than in it: a title carrying its own number reads as part of the sentence.
A glyph above the label, where a set is told apart before it is read. It stands beside the plane's own title, never alone, and is muted for the reason a card's is: a plane is a subject, not a result.
-
icon# -
- type
- string
A glyph above the label, where a set is told apart before it is read. It stands beside the plane's own title, never alone, and is muted for the reason a card's is: a plane is a subject, not a result.
Carried onto the element, for the reason the grid's is.
-
class# -
- type
- string
Carried onto the element, for the reason the grid's is.
A plane states, a card goes somewhere. That is the whole line between the
two, and it decides which one a page wants: a card's frame is the link and its
title is the anchor, so a set of planes claims nothing to click. Neither is
what .. topic:: is — a digression in the reading flow that the outline does
not list stays an <aside>, and is not one of a set.
It goes in a grid like any other set, at the width the statements
hold. A plane on its own is a plane in the flow and renders, but a single one
says nothing the paragraph above it did not. The element is sds-surface in
Content.
quote#
A sentence borrowed from somewhere, with where it came from.
.. quote:: Benjamin Kott
:as: maintainer
:meta: 24 July 2026
:initials: BK
The fallback was never the problem. *Not saying*
it was a fallback was the problem... quote:: Benjamin Kott
:as: maintainer
:meta: 24 July 2026
:initials: BK
The fallback was never the problem. *Not saying*
it was a fallback was the problem.
The fallback was never the problem. Not saying it was a fallback was the problem.
The fallback was never the problem. Not saying it was a fallback was the problem.
Who said it — a person, a document, a release note. It is the argument and not an option because the element requires it: an unattributed quotation in a product's own writing reads as the product quoting itself for emphasis, and a required thing said as an option is a thing that gets left out.
-
the argumentrequired # -
- type
- string
Who said it — a person, a document, a release note. It is the argument and not an option because the element requires it: an unattributed quotation in a product's own writing reads as the product quoting itself for emphasis, and a required thing said as an option is a thing that gets left out.
What they are to the subject, where the name alone does not say it — a
maintainer, a reviewer, the documentation. Spelt as and not role,
because role is the global ARIA attribute and would claim a role that
does not exist.
-
as# -
- type
- string
What they are to the subject, where the name alone does not say it — a maintainer, a reviewer, the documentation. Spelt
asand notrole, becauseroleis the global ARIA attribute and would claim a role that does not exist.
When, and anything else in the label register: a date, a release, a revision.
-
meta# -
- type
- string
When, and anything else in the label register: a date, a release, a revision.
Their initials, and the monogram is drawn only where they are given. A byline derives them from a name; a quotation does not, because half of what is worth quoting is a document — and a monogram of a filename is a person invented for a source that has none.
-
initials# -
- type
- string
Their initials, and the monogram is drawn only where they are given. A byline derives them from a name; a quotation does not, because half of what is worth quoting is a document — and a monogram of a filename is a person invented for a source that has none.
Where it can be read in full; the attribution becomes that link. A target pointing out of the site is left as it stands, and one pointing into it is resolved like any other reference.
-
href# -
- type
- string
Where it can be read in full; the attribution becomes that link. A target pointing out of the site is left as it stands, and one pointing into it is resolved like any other reference.
Carried onto the element, for the reason the grid's is.
-
class# -
- type
- string
Carried onto the element, for the reason the grid's is.
The sentence goes between the tags, because out of a document it carries
links and emphasis, which an attribute cannot hold. A block quote would be the
spelling to reach for and it is not available: the parser resolves an indented
block with an attribution line into a definition list, so <blockquote>
never reaches a template — this directive is how a manual quotes anything at
all. The element is sds-quote in Content, and
the attribution it draws is sds-byline, which is why there is no option
here for the order of that row.
button#
One press, and where it goes.
.. button:: :doc:`installation`
:icon: actions-download
.. button:: The renderer
:href: https://docs.phpdoc.org/components/guides/guides/
:variant: secondary
:rel: external.. button:: :doc:`installation`
:icon: actions-download
.. button:: The renderer
:href: https://docs.phpdoc.org/components/guides/guides/
:variant: secondary
:rel: external
The label, and where the press goes with it. Written as a reference, a
:doc: or an external link, the words are the label and the reference is
the target — the way a card's title carries the same thing. It is the
argument rather than an option because it is what the control says.
-
the argumentrequired # -
- type
- string
The label, and where the press goes with it. Written as a reference, a
:doc:or an external link, the words are the label and the reference is the target — the way a card's title carries the same thing. It is the argument rather than an option because it is what the control says.
The target said as a path instead, and it wins where both are written.
-
href# -
- type
- string
The target said as a path instead, and it wins where both are written.
primary, secondary or ghost. One primary per view: a second
makes neither of them mean anything.
-
variant# -
- type
- string
- default
- "primary"
primary,secondaryorghost. One primary per view: a second makes neither of them mean anything.
sm for the smaller control — a press beside a line of text rather than
under a section. lg for the one action a page is for: beside a second
large button neither of them is the one, and that is what md is for.
-
size# -
- type
- string
- default
- "md"
smfor the smaller control — a press beside a line of text rather than under a section.lgfor the one action a page is for: beside a second large button neither of them is the one, and that is whatmdis for.
A glyph before the label, and it is an icon of this system — see Icons.
The glyph is the whole control and the button is a square. It needs a name, and the label is it: the words become the control's title instead of being drawn.
-
icon-only# -
- type
- flag
The glyph is the whole control and the button is a square. It needs a name, and the label is it: the words become the control's title instead of being drawn.
What the control is called where the label does not say it, and what a pointer resting on it reads.
-
title# -
- type
- string
What the control is called where the label does not say it, and what a pointer resting on it reads.
What the target is to this page — external, prev, next. Only
with a target, being the anchor's own attribute.
-
rel# -
- type
- string
What the target is to this page —
external,prev,next. Only with a target, being the anchor's own attribute.
The control is there and cannot be pressed. It is dropped where the press goes somewhere: a link cannot be disabled, and a grey one the browser follows anyway is worse than none.
-
disabled# -
- type
- flag
The control is there and cannot be pressed. It is dropped where the press goes somewhere: a link cannot be disabled, and a grey one the browser follows anyway is worse than none.
Carried onto the element, for the reason the grid's is.
-
class# -
- type
- string
Carried onto the element, for the reason the grid's is.
A press on a rendered page is a link. Given somewhere to go the element
draws an <a>, which is what gives the reader the middle click, the hover
target and the status line the browser already has — none of which a control
with a listener on it has. A button with nowhere to go does nothing when
pressed, so type, for and command are not offered: a document has
no form to submit and no element to command, and a page that needs them is an
application rather than a manual.
The label is the words and not the markup. A reference rendered where it was written would put a link inside the control; the reference becomes the control's target instead. That is the same trade the card makes with its title, and it is why both are read off the node rather than in a template.
The element is sds-button in Controls, and it
has the properties this leaves out as well as the ones above.
button-bar#
The controls of a page, standing in one row.
.. button-bar::
.. button:: :doc:`installation`
.. button:: The renderer
:href: https://docs.phpdoc.org/components/guides/guides/
:variant: secondary
:rel: external.. button-bar::
.. button:: :doc:`installation`
.. button:: The renderer
:href: https://docs.phpdoc.org/components/guides/guides/
:variant: secondary
:rel: external
Carried onto the row, for the reason the grid's is.
-
class# -
- type
- string
Carried onto the row, for the reason the grid's is.
Named for what it holds and the shape it holds them in. A row of controls is layout rather than a component, so it has no variant:
the whole of it is that what stands in it sits on one line, centred against
each other, which is what a link beside a button needs. It holds whatever a
page puts in it, and one press in it is the primary. What it emits is
.sds-actions — the row in Page layout, written by the theme
the way band writes its section.
accordion#
Questions with their answers folded behind them, in the spelling a TYPO3 manual already uses.
.. accordion::
:group: what-a-theme-answers
.. accordion-item:: What does it need installed?
:open:
PHP 8.2 or newer, and a project it can read —
see :doc:`installation`.
.. accordion-item:: Can it run in CI?
Yes. :doc:`publishing` is the job, command for command... accordion::
:group: what-a-theme-answers
.. accordion-item:: What does it need installed?
:open:
PHP 8.2 or newer, and a project it can read —
see :doc:`installation`.
.. accordion-item:: Can it run in CI?
Yes. :doc:`publishing` is the job, command for command.
PHP 8.2 or newer, and a project it can read — see Installation.
What does it need installed?
PHP 8.2 or newer, and a project it can read — see Installation.
Yes. Publishing it, in CI is the job, command for command.
Can it run in CI?
Yes. Publishing it, in CI is the job, command for command.
PHP 8.2 or newer, and a project it can read — see Installation.
What does it need installed?
PHP 8.2 or newer, and a project it can read — see Installation.
Yes. Publishing it, in CI is the job, command for command.
Can it run in CI?
Yes. Publishing it, in CI is the job, command for command.
What the set is called. It is the group the answers fold in, so opening one closes the last — and a page with two sets gives them different names, or one closes the other's answers. A set that writes none is given one.
It is :group: and not :name: because an answer takes :name: in
the meaning every other directive gives it — the address something is
linked to. One spelling for both would be two meanings a page apart.
-
group# -
- type
- string
What the set is called. It is the group the answers fold in, so opening one closes the last — and a page with two sets gives them different names, or one closes the other's answers. A set that writes none is given one.
It is
:group:and not:name:because an answer takes:name:in the meaning every other directive gives it — the address something is linked to. One spelling for both would be two meanings a page apart.
More than one answer open at a time, for a set whose answers are meant to be compared rather than found. Without it a set is exclusive, because a list is easier to read than a wall.
-
multiple# -
- type
- flag
More than one answer open at a time, for a set whose answers are meant to be compared rather than found. Without it a set is exclusive, because a list is easier to read than a wall.
Carried onto the element, for the reason the grid's is.
-
class# -
- type
- string
Carried onto the element, for the reason the grid's is.
The fold is a <details>. It works before any script runs, the keyboard
reaches it, find-in-page opens the answer it lands in, and what closes the
others is the platform rather than a listener — which is why the answers carry
the set's name and why a page never writes one on an item. The element is
sds-accordion in Navigation.
accordion-item#
One question, and the blocks folded behind it.
.. accordion-item:: What does it need installed?
:open:
PHP 8.2 or newer, and a project it can read.
No daemon, and no database of its own... accordion-item:: What does it need installed?
:open:
PHP 8.2 or newer, and a project it can read.
No daemon, and no database of its own.
PHP 8.2 or newer, and a project it can read. No daemon, and no database of its own.
What does it need installed?
PHP 8.2 or newer, and a project it can read. No daemon, and no database of its own.
Standing open. For the first answer on a page of them, usually, so the shape
of an answer is visible without pressing anything. :show: is the same
flag under the name the Bootstrap theme gave it.
-
open# -
- type
- flag
Standing open. For the first answer on a page of them, usually, so the shape of an answer is visible without pressing anything.
:show:is the same flag under the name the Bootstrap theme gave it.
Accepted and dropped. What a set of questions is folded by is a control and not a heading, so it takes no level in the outline.
-
header-level# -
- type
- integer
Accepted and dropped. What a set of questions is folded by is a control and not a heading, so it takes no level in the outline.
The address of this one answer, for a page that links to it — written on the answer and not on the question. A fold whose content a fragment points into is opened by the platform; one that a fragment points at stays shut, which is why a link that has to show the answer aims inside it.
-
name# -
- type
- string
The address of this one answer, for a page that links to it — written on the answer and not on the question. A fold whose content a fragment points into is opened by the platform; one that a fragment points at stays shut, which is why a link that has to show the answer aims inside it.
Carried onto the element, for the reason the grid's is.
-
class# -
- type
- string
Carried onto the element, for the reason the grid's is.
The question is the argument and the answer is what follows it. That is not
a preference: an answer is paragraphs, lists and code blocks, which is what no
attribute carries. The node is sds-accordion-item itself and the template
writes none of its markup — the same arrangement as the cards above.
example#
What was written, and under it what it renders as — out of the one body.
.. example:: A press, and where it goes
.. button:: :doc:`installation`
:icon: actions-download.. example:: A press, and where it goes
.. button:: :doc:`installation`
:icon: actions-download
.. button:: :doc:`installation`
:icon: actions-download.. button:: :doc:`installation`
:icon: actions-download
The block a reader copies is the block that was run. A page that prints
markup in a code-block and then writes it a second time to render it holds
two copies of one example, and the copy nobody checks is the one being taken
away. Here the print is made of the lines the parser was handed and the
rendering is parsed from those same lines, so the two cannot come apart —
which is what specimen below does for a card, a level up.
The caption over the block: what this one shows. Left out, the block carries nothing but its language and the button that copies it.
-
the argument# -
- type
- string
The caption over the block: what this one shows. Left out, the block carries nothing but its language and the button that copies it.
What the print is coloured as. text by default because no highlighter
on this site knows reStructuredText, and a language the server cannot
colour is better said than faked; a project whose examples are written in
something it does know says so here.
-
language# -
- type
- string
- default
- "text"
What the print is coloured as.
textby default because no highlighter on this site knows reStructuredText, and a language the server cannot colour is better said than faked; a project whose examples are written in something it does know says so here.
Carried onto the frame the rendering stands in, for the reason the grid's is.
-
class# -
- type
- string
Carried onto the frame the rendering stands in, for the reason the grid's is.
The frame is dashed, and it is the only dashed line in the system. That is
what it is for: a solid one would be a box on the page, and what is inside
this one is not part of the page — it is a thing shown, at the end of a run of
things read. It is .sds-example, and it carries no fill either, so a card
or a surface in it stands on the ground it would really stand on rather than
on a plane the manual put under it.
The options are not in the print, because the parser has already taken them off the body by the time the directive sees it.
What an example cannot show is a page. The frame is a box in the column,
so a band inside one is the section a band is on a manual page rather than the
full-bleed ground it becomes on a marketing one — which is what the band above
is in an example to show. What follows a band belongs to it only where the
page is built out of bands, so a source that opens two of them renders here as
two sections with the text loose between them, and that one stays a
code-block beside prose that says so. :layout: is a field rather than
a directive and has nowhere to go in a body at all.
specimen#
A rendered card, embedded at the size it was drawn for.
.. specimen:: guidelines/colors-surfaces.card.html
:viewport: 700x270
:title: Surfaces.. specimen:: guidelines/colors-surfaces.card.html
:viewport: 700x270
:title: Surfaces
The directive's argument: a path under _cards/ in the documentation
source. The card is a whole
document with a stylesheet of its own, so it is embedded in a frame rather
than inlined — it carries the specimen chrome, which a page must not
inherit, and it may pin its own mode.
-
the cardrequired # -
- type
- string
The directive's argument: a path under
_cards/in the documentation source. The card is a whole document with a stylesheet of its own, so it is embedded in a frame rather than inlined — it carries the specimen chrome, which a page must not inherit, and it may pin its own mode.
Width by height, in pixels, and it is not decoration. Every card declares
the size it was measured at in its own @dsCard header and the gate
proves it still fits there; a card shown at any other size is a card
documenting something nobody checked.
-
viewport# -
- type
- string
- default
- "700x260"
Width by height, in pixels, and it is not decoration. Every card declares the size it was measured at in its own
@dsCardheader and the gate proves it still fits there; a card shown at any other size is a card documenting something nobody checked.
The caption under the frame, printed beside the viewport. It is also the frame's accessible name, which is the only thing a reader who cannot see the card is given.
-
title# -
- type
- string
- default
- "Specimen"
The caption under the frame, printed beside the viewport. It is also the frame's accessible name, which is the only thing a reader who cannot see the card is given.
The frame is an sds-embed — the element in
Media — fixed at the viewport above: where the
column is narrower it scrolls rather than squeezing the card into a width
nothing ever measured. Core markup, and what it becomes has the other half of that node — a
video, which is the same directive's opposite and fills the column instead.
The cards have to be inside the documentation source, because the renderer
copies an asset it can see a document reach for and nothing else. This
repository's make guides copies specimens/ into docs/_cards/ before
each render and rewrites the stylesheet links inside each card on the way —
that directory is generated and gitignored.
This directive is for a project that ships rendered cards of its own. It is what makes a guideline page show the rule instead of describing it, and it is the reason the guidelines in this manual and the specimens in Storybook cannot say different things: they are the same file.
This directive is for a project that ships rendered cards of its own. It is what makes a guideline page show the rule instead of describing it, and it is the reason the guidelines in this manual and the specimens in Storybook cannot say different things: they are the same file.
Core markup, and what it becomes for what the renderer's own directives — admonitions, code
blocks, tabs, confval, topics — come out as under this theme.
Core markup, and what it becomes for what the renderer's own directives — admonitions, code
blocks, tabs, confval, topics — come out as under this theme.
